A soldering iron works by passing an electrical current through a resistant material, which generates heat. To make a soldering iron with a nail, you can use a pen, a piece of metal with graphite, and an electrical wire. First, remove the internal components of the pen and the cap. Insert the piece of metal with graphite into the tip of the pen and pass the electrical wire through the pen, wrapping it around the metal. Connect the wire to a power supply, such as a Power Supply Unit, and touch the free end of the wire to the graphite to heat the tip. This method provides a functional iron that only stays hot when the solder is touching the graphite tip.
How to Make a Soldering Iron with a Nail
| Characteristics | Values |
|---|---|
| Power Supply | Power Supply Unit |
| Resistant Material | Graphite |
| Pros of Graphite | Has low resistance, decomposes at very high temperatures, easy to find and clean, returns to being cold quickly |
| Circuit | Connect a wire to the PSU and an end of the tip, and another wire to the PSU and the other end of the tip |
| Heating | Heat the tip by touching the graphite with the free end of the wire connected to GND |
| Safety | The iron stays hot only when the solder is touching the graphite tip |
| Shaping | Graphite can be shaped easily into a flat tip, sharp tip, etc. |
Explore related products
What You'll Learn
Remove pen internals and cap
To make a soldering iron with a nail, you'll need to start by removing the internal components of a pen. This includes the spring, cartridge, and any small gear-like parts. These parts are not necessary for the soldering iron and can be set aside.
Next, you'll need to remove the pen cap. Depending on the type of pen you're using, you may need to disassemble, cut, or break the cap to remove it. Keep in mind that a wire will need to pass through the hole left by the cap, so ensure that the hole is large enough.
Once the cap is removed, take a closer look at the piece of metal with the graphite. This will serve as your soldering tip. You'll need to insert this piece of metal into the tip of the pen, where the ink cartridge was previously located. You may need to use a file to shape the metal piece or cut the pen to ensure a snug fit.
It's important to shape the metal piece so that it can be securely inserted into the pen tip. Once you're done, simply pass an electrical wire through the pen and wrap it around one end of the metal piece. Ensure that the wire and the metal piece are securely connected and won't disconnect.
By following these steps, you'll have successfully removed the internal components and cap of the pen, ready for the next steps in creating your soldering iron.
